New / One-Trip

20ft High-Cube Shipping Container - Plywood Floor - RAL 5010 Gentian Blue

The 20ft High-Cube Shipping Container - Plywood Floor is a new high-cube unit suited to general storage, site security and international freight.

SKU:: AO-20HC-SC-PLY-NEW-RAL5010
Depot:: Long Beach, CA depot

Colour: RAL 5010 Gentian Blue

Other RAL colours are available as painted-to-order custom work — request a quotation.

$2,695

Excludes applicable sales tax and delivery. The full total is shown before payment is authorized.

In stock

Delivery available — automatic pricing for configured areas, quotation elsewhere
Pickup available from the Long Beach depot (scheduled in advance)

Quantity

max 5 per online order

Key Features

CSC plated for international transport
Corten weathering steel construction
Lockable cargo doors with galvanised locking bars
28 mm marine-grade plywood

Product Description

20FT High Cube Shipping Container

More Height. More Capacity. Same Footprint.

The 20FT High Cube Shipping Container delivers increased vertical clearance without exceeding the standard 20-foot base footprint — providing flexibility for taller cargo, stacked shelving, and space-optimized dry storage.

This container is ideal for freight transport, modular builds, and on-site applications where vertical volume is critical. It’s built from anti-corrosive CORTEN steel, fitted with ISO 668 and CSC certifications, and rated for full intermodal use across rail, road, and sea.

Key Specifications

Feature	Metric Value
External Dimensions	6.058 m (L) × 2.438 m (W) × 2.896 m (H)
Internal Dimensions	5.898 m (L) × 2.350 m (W) × 2.698 m (H)
Door Opening	2.342 m (W) × 2.585 m (H)
Internal Volume	37.40 m³
Tare Weight	2,150 kg
Max Payload	28,330 kg
Max Gross Weight	30,480 kg

Measurements conform to ISO 668 standards for global intermodal deployment.

Structural & Build Features

CORTEN Steel Construction
Durable, corrosion-resistant alloy engineered for performance in harsh weather conditions.
28mm Marine-Grade Plywood Floor
Constructed from 19-ply Keruing-Apitong hardwood; moisture-resistant, shock-absorbent, and suitable for heavy loads.
Passive Ventilation
Standard air vents reduce condensation and internal humidity for dry storage applications.
Double-Height Locking System
Offers greater mechanical leverage and enhanced security for door operations.
Forklift Pockets
Welded base inserts allow for efficient ground-level handling and relocation.
Steel Lockbox (Welded)
Integrated lockbox protects padlocks from tampering and environmental wear.
ISO Corner Castings
Compatible with standard crane lift equipment and vertical stacking procedures.
Exterior Finish
Default in RAL 5013 (Cobalt Blue); custom RAL color options available upon request.

Best Use Applications

Dry Goods Storage

Perfect for construction sites, warehouses, and inventory depots where increased height enables storage of tall items, stacked pallets, or long-form goods.

Mobile Offices or Compact Work Bays

The high cube format creates a versatile shell for office conversions or jobsite modular units.

Shelving or Equipment Housing

Supports multi-tier racking systems for tools, raw materials, and compact fabrication equipment.

Stacked Installations

Compatible with multi-container layouts in industrial yards, disaster relief bases, or space-constrained storage facilities.

Oversized Freight Transport

Accommodates tall cargo, custom machines, or materials that exceed standard height tolerances while maintaining a compact footprint.

Certification & Compliance

This container is delivered with:

CSC Plate – Valid for international intermodal transport
ISO 668 Marking – Conforms to global container classification standards
Visual Inspection Report – Confirms alignment, flooring integrity, and ventilation system functionality

All containers meet dimensional and structural benchmarks for crane lifting, shipboard use, rail loading, and flatbed freight.

Technical Specifications

Technical specifications for 20ft High-Cube Shipping Container - Plywood Floor - RAL 5010 Gentian Blue
Product type	Shipping container
Design	High-Cube
Condition	New / One-Trip
Exterior (L × W × H)	19′ 10.5″ × 8′ 0″ × 9′ 6″
Interior (L × W × H)	19′ 4″ × 7′ 8″ × 8′ 10″
Door opening (W × H)	7′ 8″ × 8′ 5″
Tare weight	≈ 5,070 lb
Max gross weight	67,200 lb
Internal capacity	≈ 1,320 cu ft
Door configuration	Double cargo doors, one end
Floor material	28 mm marine-grade plywood
Exterior colour	RAL 5010 Gentian Blue
Lockbox	Fitted
Forklift pockets	Yes
Ventilation	Passive weatherproof vents
Certification	CSC plated for international transport

What New / One-Trip Means

A new or one-trip container has generally completed one initial cargo movement from its manufacturing origin. Minor handling marks, paint abrasions, small dents, floor marks, or other transportation-related cosmetic evidence may still be present. This is normal for one-trip units and does not affect the stated condition classification.

Read the full Container Condition Guide

Delivery Requirements

Processing: 1–3 business days after payment, verification, and receipt of required information.
Delivery estimate: 5–10 business days after processing.
Site access: tilt-bed delivery of a 20ft container needs a straight, firm approach (roughly 60 feet), 12–14 feet of width, and clear overhead access free of wires and branches.
Unloading: tilt-bed standard; flatbed, crane, or chassis options are quoted based on your site.
Complex sites are switched to quotation mode so transportation can be planned correctly — request a delivered price.

Intended Uses

General storage
Site security
International freight

Customers are responsible for confirming that the product and intended use comply with applicable zoning, building, environmental, fire, safety, transportation, and permit requirements. This product is not represented as suitable for housing, food storage, hazardous materials, or regulated uses unless expressly stated in writing.

Returns and Warranty

Eligible standard product: returns may be requested within 18 calendar days of delivery, subject to authorization. Customer pays return transportation for change-of-mind returns.
Structural integrity and wind/watertight condition warranted at delivery; see Warranty Policy.

Returns and Refunds Policy Warranty Policy
