New / One-Trip

40ft High-Cube Pallet-Wide Shipping Container - Steel Floor - RAL 5010 Gentian Blue

The 40ft High-Cube Pallet-Wide Shipping Container - Steel Floor is a new high-cube unit suited to palletised freight where internal width is critical.

SKU:: AO-40HC-PW-STL-NEW-RAL5010
Depot:: Long Beach, CA depot

Colour: RAL 5010 Gentian Blue

Other RAL colours are available as painted-to-order custom work — request a quotation.

$4,159

Excludes applicable sales tax and delivery. The full total is shown before payment is authorized.

In stock

Delivery available — automatic pricing for configured areas, quotation elsewhere
Pickup available from the Long Beach depot (scheduled in advance)

Quantity

max 5 per online order

Key Features

CSC plated for international transport
Corten weathering steel construction
Lockable cargo doors with galvanised locking bars
Welded steel treadplate floor

Product Description

40FT High Cube Pallet Wide Container

Euro Pallet Optimization Meets High-Volume Efficiency

The 40FT High Cube Pallet Wide Container is purpose-built for Euro-palletized freight, delivering maximum space efficiency without sacrificing strength or compliance. With a wider internal clearance than standard ISO containers, this unit allows two Euro pallets (1200 mm x 800 mm) to be loaded side by side — eliminating wasted width and increasing payload density.

Engineered from corrosion-resistant CORTEN steel, reinforced with a durable marine-grade plywood floor, and certified for intermodal transport, this container is the preferred choice for European freight, transatlantic exports, and warehouse-based pallet storage.

Product Features

Internal Width: 2.422 m – fits two Euro pallets side by side
High Cube Format: Extra vertical clearance for stacking and light bulk cargo
Construction: Fabricated from CORTEN steel with marine-grade 28mm plywood flooring
Ventilation: Equipped with standard passive air vents
Security Fittings: Lockbox + high-position locking gear for anti-tampering security
Certification: CSC certified – export-ready, intermodal-compatible
Stackability: Engineered for vertical stacking under ISO tolerances
Color Options: RAL custom colors available upon order

Each container is built for cross-border transport, warehouse integration, and long-term storage—with Euro-pallet optimization baked into the design.

Specifications

Specification	Detail
Container Type	40FT High Cube Pallet Wide
Construction Material	CORTEN Corrosion-Resistant Steel
Flooring	28mm Marine-Grade Plywood
Ventilation	Standard Passive Vents
Security Features	Lockbox + High-Position Locking Gear
Certification	CSC Certified – Export Ready
Stackable	Yes – ISO Tolerance Compliant
Color Options	RAL Standard / Custom on Request

Dimensions & Weight

Metric	Measurement
Internal Dimensions	12.100 m (L) × 2.422 m (W) × 2.695 m (H)
External Dimensions	12.192 m (L) × 2.462 m (W) × 2.896 m (H)
Door Opening	2.416 m (W) × 2.585 m (H)
Tare Weight	4,400 kg
Max Payload	29,600 kg
Gross Weight Rating	34,000 kg

Engineering Highlights

Precision pallet spacing: Internal width allows for two Euro pallets per row, side by side
Volume advantage: High Cube format increases usable cubic meters, reducing freight cost per pallet
Heavy-duty floor: Marine plywood absorbs forklift shock and resists warping under load
Rapid deployment: Forklift pockets and ISO corner castings make this unit ready for crane or trailer use
Multi-modal usage: Certified and reinforced for sea, rail, and road shipping lanes
Stack-safe construction: Conforms to ISO load-bearing tolerances for secure vertical stacking

Ideal Use Cases

European Freight & Distribution

Perfect for logistics operators who depend on Euro-pallet workflows and need efficient load ratios on transcontinental and domestic routes.

Export & Bulk Shipping

Provides maximum internal clearance for high-volume or lightweight cargo without wasted space or over-packing issues.

Intermodal Shipping Corridors

CSC certification and ISO structure ensure compatibility with all major shipping and port handling systems.

Warehousing & Storage

Used as on-site modular storage for high-turnover palletized inventory. Color branding available for supply chain visibility.

Compliance & Customization Options

CSC Certification: Included with each unit – ready for international shipping use
RAL Colors: Choose from standard container colors or request a custom finish
Exterior Branding: Logos or stenciling available for high-volume orders
Load Testing: Units are checked for dimensional compliance and structural readiness before dispatch

Request a quote or reserve this unit today. Inspection-ready. Euro-pallet compatible. Shipping-grade certified.

Technical Specifications

Technical specifications for 40ft High-Cube Pallet-Wide Shipping Container - Steel Floor - RAL 5010 Gentian Blue
Product type	Shipping container
Design	High-Cube
Condition	New / One-Trip
Exterior (L × W × H)	40′ 0″ × 8′ 0″ × 9′ 6″
Interior (L × W × H)	39′ 5″ × 7′ 8″ × 8′ 10″
Door opening (W × H)	7′ 8″ × 8′ 5″
Tare weight	≈ 8,750 lb
Max gross weight	67,200 lb
Internal capacity	≈ 2,694 cu ft
Door configuration	Double cargo doors, one end
Floor material	Welded steel treadplate floor
Exterior colour	RAL 5010 Gentian Blue
Lockbox	Fitted
Forklift pockets	Yes
Ventilation	Passive weatherproof vents
Certification	CSC plated for international transport

What New / One-Trip Means

A new or one-trip container has generally completed one initial cargo movement from its manufacturing origin. Minor handling marks, paint abrasions, small dents, floor marks, or other transportation-related cosmetic evidence may still be present. This is normal for one-trip units and does not affect the stated condition classification.

Read the full Container Condition Guide

Delivery Requirements

Processing: 1–3 business days after payment, verification, and receipt of required information.
Delivery estimate: 5–10 business days after processing.
Site access: tilt-bed delivery of a 40ft container needs a straight, firm approach (roughly 100 feet), 12–14 feet of width, and clear overhead access free of wires and branches.
Unloading: tilt-bed standard; flatbed, crane, or chassis options are quoted based on your site.
Complex sites are switched to quotation mode so transportation can be planned correctly — request a delivered price.

Intended Uses

Palletised freight where internal width is critical

Customers are responsible for confirming that the product and intended use comply with applicable zoning, building, environmental, fire, safety, transportation, and permit requirements. This product is not represented as suitable for housing, food storage, hazardous materials, or regulated uses unless expressly stated in writing.

Returns and Warranty

Eligible standard product: returns may be requested within 18 calendar days of delivery, subject to authorization. Customer pays return transportation for change-of-mind returns.
Structural integrity and wind/watertight condition warranted at delivery; see Warranty Policy.
