New / One-Trip

40ft Open-Top Shipping Container - Plywood Floor - RAL 7042 Traffic Grey

The 40ft Open-Top Shipping Container - Plywood Floor is a new unit suited to crane or grab loading of tall and awkward cargo.

SKU:: AO-40-OT-PLY-NEW-RAL7042
Depot:: Long Beach, CA depot

Colour: RAL 7042 Traffic Gray

Other RAL colours are available as painted-to-order custom work — request a quotation.

$4,215

Excludes applicable sales tax and delivery. The full total is shown before payment is authorized.

In stock

Delivery available — automatic pricing for configured areas, quotation elsewhere
Pickup available from the Long Beach depot (scheduled in advance)

Quantity

max 5 per online order

Key Features

CSC plated for international transport
Corten weathering steel construction
Lockable cargo doors with galvanised locking bars
28 mm marine-grade plywood

Product Description

40FT Open Top Shipping Container

Maximum Capacity. Top-Loading Access. Built for Heavy Industry.

The 40FT Open Top Shipping Container is engineered for oversized or vertically loaded cargo that cannot be handled through standard container doors. With a removable roof and reinforced steel frame, it supports top-loading operations for industrial equipment, construction materials, and irregular freight.

This ISO-compliant container features a robust CORTEN steel build, marine-grade plywood flooring, and full-width end doors, making it suitable for both global transport and stationary industrial storage.

Technical Specifications

Feature	Metric
Internal Dimensions	12.032 m × 2.350 m × 2.350 m
External Dimensions	12.192 m × 2.438 m × 2.591 m
Door Opening	2.338 m × 2.228 m
Interior Volume	66.40 m³
Tare Weight	3,750 kg
Max Payload	26,730 kg
Gross Weight	30,480 kg
Standard Color	RAL5013 (other RALs optional)
Flooring	28mm Marine-Grade Plywood

All measurements conform to ISO tolerances for containerized freight systems.

Key Product Features

Removable Roof Access
Includes a tarpaulin or hard-top configuration (depending on availability) to accommodate vertical loading by crane, forklift, or overhead gantry.
Full Swing End Doors
Fitted with locking cams and an integrated lockbox system for security during transit or yard storage.
CORTEN Steel Frame
Designed to withstand corrosion and impact in harsh operational environments, from port yards to mining sites.
Stacking & Intermodal Compatibility
Certified for stacking and multi-modal freight movement via rail, truck, or sea. Fully compliant with international transport standards.
Color Customization Options
Standard finish in RAL5013. Alternate RAL colors available upon request for yard standardization or branding requirements.

Best Use Cases

Top-Loading Freight Operations

Designed for crane-accessible cargo such as steel coils, piping, scrap metal, bulk timber, or large industrial tools. Eliminates door clearance limitations common to closed-box containers.

Oversized Machinery Transport

Enables secure loading of equipment with uneven dimensions, hydraulic arms, or upward protruding components that require drop-in or vertical handling.

Heavy Industry & Energy Infrastructure

Used in mining, fabrication plants, offshore facilities, and power generation sites where rugged, weather-resistant storage is essential.

Cross-Border and Intermodal Shipping

Meets ISO and CSC requirements for integration into global shipping lanes and multi-modal supply chains. No modification required for rail or marine transport.

Yard-Based Storage

Ideal for static use on construction sites, distribution hubs, or material storage yards requiring overhead loading or equipment accessibility.

Certification & Compliance

CSC Certified
Each container includes a valid Convention for Safe Containers (CSC) plate and is cleared for international transport and stacking operations.
Pre-Dispatch Inspection
All containers are inspected for:
- Structural welds and frame integrity
- Door function and seal integrity
- Flooring quality and load-bearing status
- Roof fixture functionality and weather tightness
Documentation Provided
Inspection photos, CSC documentation, and dimensional diagrams are available upon request. Custom delivery notes or condition reports may be issued for government or industrial procurement departments.

Availability & Customization

This unit is available for immediate deployment within the United States or for export. Custom lead times may apply when requesting alternate roof configurations or non-standard color finishes. Contact for up-to-date availability based on your loading method and operating environment.

Technical Specifications

Technical specifications for 40ft Open-Top Shipping Container - Plywood Floor - RAL 7042 Traffic Grey
Product type	Shipping container
Design	Open-Top
Condition	New / One-Trip
Exterior (L × W × H)	40′ 0″ × 8′ 0″ × 8′ 6″
Interior (L × W × H)	39′ 5″ × 7′ 8″ × 7′ 10″
Door opening (W × H)	7′ 8″ × 7′ 5″
Tare weight	≈ 8,000 lb
Max gross weight	67,200 lb
Internal capacity	≈ 2,390 cu ft
Door configuration	End cargo doors; removable roof for top loading
Floor material	28 mm marine-grade plywood
Exterior colour	RAL 7042 Traffic Grey
Lockbox	Fitted
Forklift pockets	Yes
Ventilation	Passive weatherproof vents
Certification	CSC plated for international transport

What New / One-Trip Means

A new or one-trip container has generally completed one initial cargo movement from its manufacturing origin. Minor handling marks, paint abrasions, small dents, floor marks, or other transportation-related cosmetic evidence may still be present. This is normal for one-trip units and does not affect the stated condition classification.

Read the full Container Condition Guide

Delivery Requirements

Processing: 1–3 business days after payment, verification, and receipt of required information.
Delivery estimate: 5–10 business days after processing.
Site access: tilt-bed delivery of a 40ft container needs a straight, firm approach (roughly 100 feet), 12–14 feet of width, and clear overhead access free of wires and branches.
Unloading: tilt-bed standard; flatbed, crane, or chassis options are quoted based on your site.
Complex sites are switched to quotation mode so transportation can be planned correctly — request a delivered price.

Intended Uses

Crane or grab loading of tall
Awkward cargo

Customers are responsible for confirming that the product and intended use comply with applicable zoning, building, environmental, fire, safety, transportation, and permit requirements. This product is not represented as suitable for housing, food storage, hazardous materials, or regulated uses unless expressly stated in writing.

Returns and Warranty

Eligible standard product: returns may be requested within 18 calendar days of delivery, subject to authorization. Customer pays return transportation for change-of-mind returns.
Structural integrity and wind/watertight condition warranted at delivery; see Warranty Policy.
