New / One-Trip

40ft High-Cube Double-Door Shipping Container - Plywood Floor - RAL 7035 Light Grey

The 40ft High-Cube Double-Door Shipping Container - Plywood Floor is a new high-cube unit suited to drive-through loading and split-load handling.

SKU:: AO-40HC-DD-PLY-NEW-RAL7035
Depot:: Long Beach, CA depot

Colour: RAL 7035 Light Gray

Other RAL colours are available as painted-to-order custom work — request a quotation.

$3,725

Excludes applicable sales tax and delivery. The full total is shown before payment is authorized.

In stock

Delivery available — automatic pricing for configured areas, quotation elsewhere
Pickup available from the Long Beach depot (scheduled in advance)

Quantity

max 5 per online order

Key Features

CSC plated for international transport
Corten weathering steel construction
Lockable cargo doors with galvanised locking bars
28 mm marine-grade plywood

Product Description

40FT High Cube Double Door Shipping Container

Dual Access. Maximum Flexibility. Engineered for Efficiency.

The 40FT High Cube Double Door Shipping Container delivers high-volume storage and unmatched accessibility with cargo doors at both ends. Designed to support zone-based loading, inventory separation, and efficient freight handling, this unit is ideal for commercial, industrial, and intermodal use.

Its high cube height of 9’6” allows for increased internal clearance, while marine-grade CORTEN steel construction provides long-lasting resistance against corrosion, weather, and operational wear.

This container is ISO-compliant, CSC certified, and ready for international transport or site-based storage operations.

Specifications Overview

Attribute	Specification
External Dimensions	12.192 m × 2.438 m × 2.896 m
Internal Dimensions	11.978 m × 2.350 m × 2.689 m
Door Openings (Both Ends)	2.340 m W × 2.585 m H
Internal Volume	76 cubic meters
Tare Weight	4,100 kg
Max Payload	26,380 kg
Max Gross Weight	30,480 kg
Stackability	ISO-compliant, fully stackable
Color (Standard)	RAL 5013 Blue (custom RAL options available)

Construction & Functional Features

Container Type: 40FT High Cube with Double End Doors
Material: CORTEN marine-grade corrosion-resistant steel
Doors:
- Dual ISO swing doors (front and rear)
- Integrated lockboxes on both ends
- Reinforced locking gear with double-high bar system
Ventilation: Standard passive air vents on both sides
Flooring:
- Standard: Hardwood marine-grade plywood
- Optional: Steel plate flooring (by request)
Certification: CSC certified for intermodal and international use
Handling Compatibility:
- Forklift pockets
- Crane corner castings
- Chassis/trailer systems for overland transport

Performance & Structural Integrity

ISO 1496-1 compliant for stacking, lifting, and securement across global freight platforms
Weather-sealed and reinforced for long-term external use in warehouse yards, job sites, or exposed terminals
Increased ceiling height allows greater storage density and supports tall equipment, stacked pallets, or modular interior designs
Dual access points reduce turnaround time for loading and unloading operations, eliminating the need to shift inventory
Lockable doors at both ends provide added control over cargo zones and security during transit or static deployment

Applications & Use Cases

Warehouse & Inventory Management

Supports dual-end entry for zone storage, quick inventory rotation, and streamlined loading dock operations.

Agricultural & Farm Use

Provides front and rear access to store grains, feed, or equipment without repositioning contents.

Construction & Field Deployment

Ideal for mobile site offices, tool lockups, and equipment segregation in rotating job sites.

Modular Conversion & Custom Builds

Used in pop-up retail, container cafés, mobile field units, or duplex access structures with custom partitioning.

Intermodal & Export Logistics

Compliant with global shipping standards, ready for port handoffs, train loading, and overland haulage.

Delivery & Inspection Readiness

Each 40FT High Cube Double Door Shipping Container is:

Built to ISO 1496-1 standards
Inspected for frame integrity, floor strength, door alignment, and seal condition
Delivered with lifting-ready corner castings and chassis compatibility
Available with optional modifications upon request (color, flooring, locks)

Inspection reports and scaled dimensional drawings are available prior to delivery.

Technical Specifications

Technical specifications for 40ft High-Cube Double-Door Shipping Container - Plywood Floor - RAL 7035 Light Grey
Product type	Shipping container
Design	Double-Door / Tunnel
Condition	New / One-Trip
Exterior (L × W × H)	40′ 0″ × 8′ 0″ × 9′ 6″
Interior (L × W × H)	39′ 5″ × 7′ 8″ × 8′ 10″
Door opening (W × H)	7′ 8″ × 8′ 5″
Tare weight	≈ 8,750 lb
Max gross weight	67,200 lb
Internal capacity	≈ 2,694 cu ft
Door configuration	Full-width cargo doors at both ends
Floor material	28 mm marine-grade plywood
Exterior colour	RAL 7035 Light Grey
Lockbox	Fitted
Forklift pockets	Yes
Ventilation	Passive weatherproof vents
Certification	CSC plated for international transport

What New / One-Trip Means

A new or one-trip container has generally completed one initial cargo movement from its manufacturing origin. Minor handling marks, paint abrasions, small dents, floor marks, or other transportation-related cosmetic evidence may still be present. This is normal for one-trip units and does not affect the stated condition classification.

Read the full Container Condition Guide

Delivery Requirements

Processing: 1–3 business days after payment, verification, and receipt of required information.
Delivery estimate: 5–10 business days after processing.
Site access: tilt-bed delivery of a 40ft container needs a straight, firm approach (roughly 100 feet), 12–14 feet of width, and clear overhead access free of wires and branches.
Unloading: tilt-bed standard; flatbed, crane, or chassis options are quoted based on your site.
Complex sites are switched to quotation mode so transportation can be planned correctly — request a delivered price.

Intended Uses

Drive-through loading
Split-load handling

Customers are responsible for confirming that the product and intended use comply with applicable zoning, building, environmental, fire, safety, transportation, and permit requirements. This product is not represented as suitable for housing, food storage, hazardous materials, or regulated uses unless expressly stated in writing.

Returns and Warranty

Eligible standard product: returns may be requested within 18 calendar days of delivery, subject to authorization. Customer pays return transportation for change-of-mind returns.
Structural integrity and wind/watertight condition warranted at delivery; see Warranty Policy.

Returns and Refunds Policy Warranty Policy
